IPG CNC Sheet Metal Enclosed Laser Cutting Machine With Raytools Laser Head

Certification : CE

MOQ : 1

Delivery Time : 7-30days

Payment Terms : T/T

Cutting Area : 1500mm*3000mm

Cutting Speed : 0~100m/min

Graphic Format Supported : AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP

Cutting Thickness : 0~30mm

Cooling Mode : WATER COOLING

Control Software : CYPCUT

Laser Source Brand : MAX Raycus

Laser Head Brand : Raytools

Servo Motor Brand : Yaskawa

Guiderail Brand : HIWIN

Control System Brand : Cypcut

Weight (KG) : 3500 KG

Optical Lens Brand : Wavelength

Warranty : 3 years

Core Components : Pressure vessel, Motor, Gear, Gearbox, Engine, PLC

Mode of Operation : continuous wave

Configuration : gantry type

Contact Now

Power IPG CNC Sheet Metal Plate Fiber Laser Cutting Machine With Raytools Laser Head

Products Description

IPG CNC Sheet Metal Enclosed Laser Cutting Machine With Raytools Laser Head

SPECIFICATIONS
Cutting Area	3000mm X 1500mm	4000mm X 2000mm	6000mm X 1500mm	6000mm X 2000mm
Positioning Accuracy	≤0.03mm	≤0.03mm	≤0.03mm	≤0.03mm
Repositioning Acc.	≤0.02mm	≤0.02mm	≤0.02mm	≤0.02mm
Max. Linkage Speed	90m/min	90m/min	100m/min	100m/min
Laser Power	1000W / 1500W / 2000W / 3000W / 6000W / 12000W / 15000W / 20000W / 30000W
Laser Source	Max / Raycus / IPG / Boci / BWT
Max Acceleration	1.2G	1.2G	1.5G	1.5G
Power Supply	AC380V/50Hz 60Hz	AC380V/50Hz 60Hz	AC380V/50Hz 60Hz	AC380V/50Hz 60Hz

FAQ:

1. What is the maximum cutting area of your IPG CNC laser cutting machine?

We offer four standard cutting bed sizes:

3000mm × 1500mm (3m × 1.5m)
4000mm × 2000mm (4m × 2m)
6000mm × 1500mm (6m × 1.5m)
6000mm × 2000mm (6m × 2m)**
Custom sizes are available upon request for industrial-scale projects.

2. How precise is your laser cutter?

Our machine guarantees high precision:

Positioning accuracy: ≤0.03mm
Repositioning accuracy: ≤0.02mm
Max acceleration: 1.2G–1.5G (varies by model)
This ensures flawless cuts for intricate sheet metal designs.

3. What laser power options are available?

Choose from a wide power range to match your material thickness:

Standard options: 1000W, 1500W, 2000W, 3000W
High-power options: 6000W, 12000W, 15000W, 20000W, 30000W
Higher wattage is ideal for thick metals (e.g., 30mm steel).

4. Which laser sources do you support?

Our machines are compatible with top-tier laser sources, including:

IPG (High-efficiency fiber lasers)
Raycus / Max (Cost-effective alternatives)
Boci / BWT (Regional preferences)
IPG is recommended for demanding industrial applications.

5. What is the maximum cutting speed?

Linkage speed: Up to 90–100m/min (depends on model)
Acceleration: 1.2G–1.5G
This ensures rapid production for bulk orders without sacrificing accuracy.

6. What electrical supply is required?

All models operate on AC380V/50Hz or 60Hz power. We provide guidance on voltage stabilization and safety setups for your factory.
